Expressway Guardrail

Description of Guardrail, highway guardrail: 1. W-Beam (thrie-beams are also available) 2. Base steel: Q235 (S235JR / ASTM A283M)or Q345 (S355JR / ASTM A529M 1994) 3. Norma specification: 380*85*2.75/3/4*4128/4320mm or 306*80*2.75/3/4*4300mm 3. Hot dipped galvanized finish or powder coated. 4. Zinc coating thickness (double sides): 550 g/m2 (40µ) / 1100 g/m2 (80µ) / 1200 g/m2 (85µ) 5. Relevant parts required for guardrails: post, spacer (C,U and Sigma types etc) and fasteners 6. Other specialspecificationas per client's requirement or drawings. We are a reputable manufacturer specialized in highway guardrail since 1994. We are also a contractor of highway guardrails, also we do installation. We export worldwide. We can manufacture W Beam (Profile A), Profile B, and different types of steel posts (C Posts, U Posts, Sigma Posts) and blocks, we can also supply bolts, nuts and washers, reflector, cat's eye, and relevant components, etc. We manufacture highway guardrails mainly according to those Standards below: a. JT/T 281-1995(Corrugated Sheet Steel Beams For Expressway Guardrail - China) b. AASHTO-M180 (Corrugated Sheet Steel Beams For Highway Guardrail - USA) c. RAL RG620 (Germany) d. Or tailor-make according to client's requirements 1. Types: Type I. hot dip galvanized: 550 g/m2 (40µ) Type II. hot dip galvanized:1100 g/m2 (80µ) or 1200 g/m2 (85µ) 2. Class: Class A-1: 2.67 mm base metal nominal thickness, Steel Grade Q235 (equivalent to S235JR according to DIN EN10025 and Gr.D according to ASTM A283M) Class A-2: 2.67 mm base metal nominal thickness, Steel Grade Q345 (equivalent to S355JR according to DIN EN10025 1994 and Gr.50[345] according to ASTM A529M) Class B-1: 3.43 mm base metal nominal thickness, Steel Grade Q235 (equivalent to S235JR according to DIN EN10025 and Gr.D according to ASTM A283M) Class B-2: 3.0 mm base metal nominal thickness, Steel Grade Q235 (equivalent to S235JR according to DIN EN10025 and Gr.D according to ASTM A283M) 3. Ordering Information 3.1.1 Quantity (number of pieces or linear meter) 3.1.2 CLASS of Guardrail 3.1.3 TYPE of Guardrail: 3.1.4 Effective Length: 3.2m or 3.81m or 4.0m 3.1.5 Shape: W Beam or Profile B or Thrie Beam 3.1.6 Exceptions and Special Requirements: A. Effective length and Overall length see manufacturer's drawing B. Base Metal Steel Grade: C. Bolts, Nuts and Washers D. Markings
